CYCLOIDAL GEARBOX

SRV Series

Precision reduction gear SRV-E is a reduction gear for precise motion control which uses a planetocentric reduction gear mechanism. SRV-E series is developed for robotic industries. The compact and light weight could reduce the inertia of robot swing to achieve more precise positioning.



Technical Parameters

  • Rated Torque: 72NM - 4410NM
  • Reduction Ratio: 1:78 - 1:301
  • Backlash: <3 - 1Arcmin
  • Model: 6E to 450E






SRV-E Series : Cycloidal Gearbox

This reduction gear design has advantages in rigidity and resistance against overload with a compact body due to a large number of simultaneously engaged gear teeth. Furthermore, minimal backlash, rotational vibration and low inertia lead to rapid acceleration, smooth motion and accurate positioning.


Our Features





  • Large flange rotary face.
  • Wide range of reduction with high rated torque capacity in short axial dimension.





  • High load carrying capacity.
  • Precision backlash which make suitable to use in robotic arm.
